I'm using USB UART not the PI's on board Uart
https://postimg.cc/zbQpDLh5
Image may be NSFW.
Clik here to view.
These are the correct numbers from the datasheet I double checked but it seems to pass the CRC check right?
https://postimg.cc/zbQpDLh5
Image may be NSFW.
Clik here to view.

These are the correct numbers from the datasheet I double checked but it seems to pass the CRC check right?
Code:
#!/usr/bin/pythonimport serial, os, time, sys, datetime, csv#Function to calculate MH-Z19 crc according to datasheetdef crc8(a): crc=0x00 count=1 b=bytearray(a) while count<8: crc+=b[count] count=count+1 #Truncate to 8 bit crc%=256 #Invert number with xor crc=~crc&0xFF crc+=1 return crc # try to open serial port port='/dev/ttyUSB0'sys.stderr.write('Trying port %sn' % port) try: # try to read a line of data from the serial port and parse with serial.Serial(port, 9600, timeout=2.0) as ser: # 'warm up' with reading one input result=ser.write("xffx01x86x00x00x00x00x00x79") time.sleep(0.1) s=ser.read(9) z=bytearray(s) # Calculate crc crc=crc8(s) if crc != z[8]: sys.stderr.write('CRC error calculated %d bytes= %d:%d:%d:%d:%d:%d:%d:%d crc= %dn' % (crc, z[0],z[1],z[2],z[3],z[4],z[5],z[6],z[7],z[8])) else: sys.stderr.write('Logging data on %s to %sn' % (port, logfilename())) # log data outfname = logfilename() with open(outfname, 'a') as f: # loop will exit with Ctrl-C, which raises a KeyboardInterrupt while True: #Send "read value" command to MH-Z19 sensor result=ser.write("xffx01x86x00x00x00x00x00x79") time.sleep(0.1) s=ser.read(9) z=bytearray(s) crc=crc8(s) #Calculate crc if crc != z[8]: sys.stderr.write('CRC error calculated %d bytes= %d:%d:%d:%d:%d:%d:%d:%d crc= %dn' % (crc, z[0],z[1],z[2],z[3],z[4],z[5],z[6],z[7],z[8])) else: if s[0] == "xff" and s[1] == "x86": print ("co2=", ord(s[2])*256 + ord(s[3])) co2value=ord(s[2])*256 + ord(s[3]) now=time.ctime() parsed=time.strptime(now) lgtime=time.strftime("%Y %m %d %H:%M:%S") row=[lgtime,co2value] w=csv.writer(f) w.writerow(row) #Sample every minute, synced to local time t=datetime.datetime.now() sleeptime=60-t.second time.sleep(sleeptime)except Exception as e: ser.close() sys.stderr.write('Error reading serial port %s: %sn' % (type(e).__name__, e))except KeyboardInterrupt as e: f.close() ser.close() sys.stderr.write('nCtrl+C pressed, exiting log of %s to %sn' % (port, outfname))
Statistics: Posted by Hydrogrower — Thu Jan 11, 2024 2:02 pm
